Application:
1. This screw oil press is an advanced expeller, can cold press and hot press pr oil from vegetable oil seeds, such as soybean, peanut, sunflower, cotton, sesame, tea seed, copra, jatropha seeds, castor seed, etc.
2. The product oil is for both edible and biodiesel fuel purposes.
3. Machine materials:
· Pressing screws parts are made of Heat treated alloy steel
· Machine's main body is made of high-quality ductile cast iron (impact resistant)
· Gears inside the gearbox are made of all-steel;
· Oil tray and oil cover are made in stainless steel
Advantage
1.Simple and easy operation,one key to start without other operating
2.Oil residue in cake less than 7%
3.Reliable transmission systems are mostly helical gears with greater torque
4. Pure copper motors are more powerful and less failure rate
5. Reasonable design and configuration of strip and round row ensure faster oil output and higher oil yield
6. Stainless steel oil guide plate is cleaner and more sanitary
7 Advanced automatic stirring forced feeding system ensures the uniformity and continuity of feeding
8.Convenient and labor-saving adjustment and disassembly system facilitates product adjustment and maintenance
9.Stainless steel hopper, cover and oil guide plate make the oil healthier and sanitary, and easy to clean
Technical data:
|
Model |
Capacity(kg/h) |
Power(kw) |
Machine Size(mm) |
Weight(kg) |
|
6YL-68 |
50kg/h |
5.5kw |
930x490x820 |
150kg |
|
6YL-68C |
50kg/h |
5.5kw |
930x575x1055 |
150kg |
|
6YL-68J |
50kg/h |
5.5kw |
930x575x1055 |
150kg |
|
6YL-80 |
100kg/h |
5.5kw |
1307x550x1102 |
300kg |
|
6YL-95 |
200kg/h |
7.5-11kw |
2155x580x1250 |
550kg |
|
6YL-100 |
200kg/h |
7.5-11kw |
2050x550x1180 |
550kg |
|
6YL-120 |
300kg/h |
11-15kw |
2150x610x1300 |
700kg |
|
6YL-130 |
450kg/h |
15-18.5kw |
2180x610x1480 |
800kg |
|
6YL-160 |
550kg/h |
18.5-22kw |
2180x610x1480 |
900kg |
| 6YL-165 |
700kg/h |
22-30kw |
2280x620x1680 |
1300kg |
More pictures and details
Rod and round ring in the oil press machine
6YL-160 oil expeller assembly/disassembly of Pressing cage
(Round rings,square rods holder)
1. Round plate No.1 2.Round plate No.2
3-6.Round plate No.3-6 7. Round plate No.7
8-15. Round plate No.8-15 16. Round plate No.16
17.Round plate No.17 18. Round plate No.18
19.Round plate No.19 20.Adjustable bolt
21. Rods holder 22. Pressing rods
23. Short flat key 24.Upper pressing cage
25.Long flat key 26. Under pressing cage
Pressing screw:
|
Item |
Description |
Quantity /set |
Item |
Description |
Quantity /set |
|
1 |
screw shaft |
1 |
15 |
tight nut |
1 |
|
2 |
long flat key |
1 |
16 |
adjusting bolt |
1 |
|
3 |
intermediate ring |
1 |
17 |
big handle |
4 |
|
4-11 |
worm No.1-8 |
1 |
18 |
adjusting bolt bush |
2 |
|
12 |
cake guide ring |
1 |
19 |
end nut |
2 |
|
13 |
press nut |
1 |
20 |
safe cover |
1 |
|
14 |
bearing 8309 |
2 |
Other spare parts for oil press machine
Package: First of all, use film winding waterproof and dustproof, and then packed into wooden cases, packing straps tied strong
